A space is defined
by the void you
decide to carve.

We build from structural mass inwards. Light is calculated as a permanent material, sculpting thermal inertia and spatial gravity.

■ EXPLORE WORKSTHE SOLAR MODEL
Board-formed concrete pavilion maquette with carved voids, a courtyard and an exposed staircase+ 08 / STRUCTURAL MASS
MODEL 08 · BOARD-FORMED CONCRETE 1:50
HOUSING IN AGUA DULCE · ARCHIVE REF. 24–09
SCROLL TO INVESTIGATE
01 / THE CONSTRUCTIVE SECTIONMASS BEFORE FORM. STRUCTURE BEFORE SURFACE.

Not an addition.
An act of subtraction.

Our architecture begins with a solid. We remove only what is necessary — a passage, a courtyard, an aperture for light. What remains is both structure and expression.

01 / ENVELOPE
Mass cast-in-place concrete with lime pozzolana additive. A continuous, 500 mm structural skin.
02 / GLAZING
Deep structural reveals inset 420 mm to prevent solar gain at zenith.
03 / THERMAL MASS
High nocturnal dissipation through cross-courtyard ventilation.
SECTION A—A / 1:50
01 / ENVELOPE8 4003 200± 0.00+ 3.20COURTYARD
500 MM / CAST-IN-PLACE CONCRETEDRAWING 08.01
02 / HELIOTHERMAL STUDY37.3891° N · SUMMER SOLSTICE

Following the
weight of light.

A calculated relationship between the sun, the reveal, and the inhabited void. The building holds still. Everything else moves.

21 JUNE / SEVILLE09:24 CET
E / 112°W / 248°SN ↑PLAN 0871°53.3° ELEV.
SOLAR ELEVATION53.3°
AZIMUTH139°
ESTIMATED LUX AT REVEAL3098 lm
FIG. 02
SOLAR INCIDENCE
SCHEMATIC SIMULATION
03 / MATERIAL & TECTONIC TAXONOMYA PALETTE OF PERMANENCE

The matter of making.

Raw. Local. Left to weather.

[CODE][MATERIAL][QUARRY / SOURCING][kgCO₂/m³][SURFACE TREATMENT]
01HYDRAULIC LIMEMorón de la Frontera, ES148Hand-trowelled / unsealed
02UNTREATED REINFORCED CONCRETELocal aggregate, Andalucía240Board-formed / raw cast
03WEATHERING CORTEN STEELReclaimed stock, Bilbao1 850Naturally oxidised
04FLAMED SIERRA GRANITESierra de los Santos, ES92Flamed / brushed
04 / SELECTED WORK ARCHIVE2018 — 2024 / BUILT & INHABITED

Measured in place.

INDEX / 05 ENTRIES
[REF][PROJECT NAME][TYPOLOGY][AREA][LOCATION][COMPLETION]
